Explorer 1000 Plus Basic Information

Battery Capacity

1264Wh

Type of Battery Used

LiFePO₄

Battery Cycle Life (Durability)

4000 cycles≥70%

Type of Product Output Current

Pure Sine Wave

Product Dimensions (cm) (W)Length × (D)Width × (H)Height

35.6 × 26.0 × 28.3

Product Weight

Around 14.5Kg

Product Color

Black

Product AC Input Specification

120V, 60Hz, Max. 15A (Max. Input Power: 1200W ± 50W)

Minimum Power Required for Product AC Input

Over 1400W

DC Input Specification (Solar Power Input Specification)

Supports 12–60V Single Port Usage: Current Limit 11A, Max. Input Power 400W Dual Port Usage: Current Limit 22A, Max. Input Power 800W

DC Input Specification (Car Charger Input Specification)

12V, Current Limit 11A

Number of Input Ports When Charging Product with DC (Panel Charger/Car Charger)

2

Input Port for Charging Product with Solar Panel

DC8020

Input Port for Charging Product with Car Charger Port

DC8020

Product AC Charging Time

Around 1.7H

Product Charging Time with Car Charger Port

Around 14.5H

Product Charging Time with Solar Panel Solarsaga40

No Verified Data

Product Charging Time with Solar Panel Solarsaga80

No Verified Data

Product Charging Time with Solar Panel Solarsaga100

1 Panel: Around 18H 2 Panels: Around 9H 4 Panels: Around 4.5H

Product Charging Time with Solar Panel Solarsaga200

1 Panel: Around 9H 2 Panels: Around 4.5H 4 Panels: Around 2H

Product Charging Time with Solar Panel Solarsaga 500 X

/

Product Charging Time with Roof High Voltage Solar System

/

Product AC Output Specification

120V/20A, Max. 2000W Per Port; Max. 2000W Total For 3 Ports.

Maximum Instantaneous Output Power

4000w

Number of Product AC Output Ports

3

AC Output Frequency

60HZ

Product Car Charger Port Specification

12V/10A

Number of Product Car Charger Ports

1

Number of Product USB Ports

4

Product USB-A Port Output Specification

Max. 18W

Product Specification for Input via USB-C Port

No USB-C Input Port

Product USB-C Port Output Specification

2*USB-C: Max. 100W

Temperature Range for Product Charging

0 ℃ ~ 45 ℃

Discharge Temperature Range

-10 ℃ ~ 45 ℃

Storage Temperature Range

1 Month: -20 ℃ ~ 45 ℃; 3 Months: 0 ℃ ~ 45 ℃; 1 Year: 0 ℃ ~ 25 ℃

Material of Product Housing

PC + ABS High-Strength Plastic

Product Warranty Period

Standard Warranty: 3 Years. Extendable by 2 Years for a Max Total of 5 Years.

Accessories

1 * Portable Power Station 1 * AC Charging Cable 1 * Car Charging Cable (8020) 1 * User Manual

Noise Level of Product Cooling Fan

≤ 45dB

Standby Power Consumption

22W

Does it Have EPS Function

Connect the electrical appliance plug to the AC output port of the portable power station, and connect the portable power station to a household wall outlet using the AC charging cable. Even in the event of a power outage, the unit is equipped with an EPS function that automatically switches to battery power within 20 ms (0.020 seconds). In the case of a sudden power failure, power supply can continue within the remaining battery capacity of the portable power station. However, the EPS function does not support 0 ms (instantaneous) switching. Therefore, devices such as data servers and workstations that require full UPS functionality (no momentary power interruption) are not supported. Thank you for your understanding in advance.

Are additional accessories required to connect the solar panel?

■ Regarding the necessity of purchasing additional series boxes: Connecting 1 or 2 Panels: Can be connected using the included cable. No additional purchase required. Connecting 3 Panels: Requires 1 × SolarSaga Adapter (for Pro/Plus/V Series). Connecting 4 Panels: Requires 2 × SolarSaga Adapters (for Pro/Plus/V Series).

Does the AC charging cable include a grounding wire, and how should it be used?

Grounding wire included.

Maximum Number of Solar Panels That Can Be Connected

Supports connection for 1 panel / 2 panels / 3 panels / 4 panels.

Supports Charging with Jackery Products?

When charging this unit from the AC output of portable power station A, it is supported if A's “AC output” is 1400W or higher.

Maximum AC output power during simultaneous charging and discharging

12A Max in Simultaneous Charging and Discharging Mode

Maximum DC output (car charging port output) power during simultaneous charging and discharging

12V, 10A, Max. 120W

Can the product connect to 2 solar panels

Supported. The two DC input ports are independent, so they support connecting panels even with different wattages.

Can the product connect to 3 or more solar panels

Supports connection of 3 panels: Use a Solar panel connector to combine 2 panels and connect them to DC Input 1. Connect the remaining panel directly to DC Input 2. ※ All panels connected to the Solar panel connector must have the same output and model. (e.g., all 100W (JS-100F) or all 200W (JS-200D)) ※ Do not connect all three panels together using a single adapter (risk of overvoltage). Connecting 4 panels: Use adapters to combine 2 panels each, and connect them separately to DC Input 1 and DC Input 2. ※ All panels connected to the Solar panel connector must have the same output and model. (e.g., all 100W (JS-100F) or all 200W (JS-200D))

Are the two DC input ports parallel or independent

Independent

Connection rules when both DC ports are used simultaneously

The unit has two DC input ports, each supporting a maximum of two solar panels. Neither the quantity nor the model of solar panels connected to each port needs to be consistent.

Can the product be charged by a solar panel and a car charger at the same time?

Supported.

Can the product be charged using two car charging cables at the same time?

Supported.

Does the product support battery packs?

The product supports battery packs (compatible with the E1000 Plus), with up to 3 packs usable simultaneously.

Does the product support app control?

Supported.

Does it have waterproof and dustproof?

Not supported.

Can the AC output frequency be switched

Not supported.

Does the product support parallel operation

Not supported.

Is the AC charging cable UL certified?

Yes, the AC charging cable included with the portable power supply bears the UL certification mark, ensuring safe use.

Does it have LED lighting

Supported.

Can it be charged using a car fast charger?

Supported.

Charging time with car fast charger

No Verified Data

Can wall charging and Solar charging be performed simultaneously

Supported.

Can the Energy Saving Mode be turned off

Supported.

Can the device status be monitored via the app

Supported.

Can the AC/DC output be turned on/off via the app

Supported.

Can the LED display be turned on or off and scheduled via the app

Supported.

Can the LED light be turned on or off via the app?

Supported.

Does the app allow setting auto-shutdown?

Supported.

Is it possible to set Battery Saving Mode in the app

Supported.

Is it possible to set Quiet Charging Mode in the app

Supported, but not supported when connected to the back of the battery.

Can product specifications be viewed in the app

Supported.

Can the user manual be accessed through the app

Supported.

Can the device be shared using a QR code

Supported.

Can the temperature display be set in the app

Supported.

Is it possible to configure the system language through the app

Supported.

Is it possible to set the Battery saving mode (15% to 85%) in the app

Supported, but not supported when connected to the back of the battery.

Can the charging range for Battery saving mode be adjusted via the app

Not supported.

Is it possible to set the emergency charging mode in the app

Not supported.

Does it have solar power generation analytics?

Not supported.

Does it have a timed charging (charging plan) function

Not supported.

Does this system have a Self-powered Mode

Not supported.

Can the Wi-Fi MAC address be viewed in the app

Not supported.

Is it possible to set AC charging speed in the app

Not supported.

Can the AC/DC output time be set through the APP?

Not supported.

Plug type and usage scenario for the 30A output port on Power Station

/

Plug type and usage scenario for the 50A output port on Power Station

/

Does it support pass-through charging?

Yes, supported. Additionally, the pass-through mode allows simultaneous charging and discharging, so using the portable power supply while charging does not affect its lifespan.

Location of the SN

The SN is located on the back of the device.

How to reset the device

Press and hold both the Power and USB buttons simultaneously for five seconds. The screen will briefly turn off and then relight, displaying the remaining battery percentage — this confirms the reset was successful.

Can Wi-Fi/Bluetooth be reset separately

Yes

How to reset Wi-Fi/Bluetooth

Press and hold both the Power and USB buttons simultaneously for five seconds. The screen will briefly turn off and then relight, displaying the remaining battery percentage — this confirms the reset was successful.

How to activate the Bluetooth/Wi-Fi module after it has been turned off.

Press and hold the USB and AC buttons simultaneously for 3 seconds.

How much battery capacity is typically lost due to self-discharge when the power station is not in use?

Around 1%-3% per month

About app settings when the battery is fully depleted For example, if the current app settings are “Battery Saving Mode

Disabled” and “Auto Power-Off: Never,” will these settings remain the same after the battery is drained and then recharged? Or will they be reset to default?: These settings will remain unchanged once the battery is restored, provided no reset is performed.

Is the neutral wire floating or Bonded?

floating
