HomePower 3600 Pro Max Basic Information

Battery Capacity

3584Wh

Type of Battery Used

LiFePO₄

Battery Cycle Life (Durability)

6000Cycles≥70%

Type of Product Output Current

Pure Sine Wave

Product Dimensions (cm) (W)Length × (D)Width × (H)Height

37.5x27.5x45cm

Product Weight

33.5 Kg

Product Color

Black

Product AC Input Specification

AC100V~120V, 60Hz, 15Amax

Minimum Power Required for Product AC Input

1800W

DC Input Specification (Solar Power Input Specification)

Single channel: 16–60 V (operating voltage)/12 A max; dual channels: 24 A/1200 W max

DC Input Specification (Car Charger Input Specification)

Single channel: 12–16 V/8 A max; dual channels: 8 A max

Number of Input Ports When Charging Product with DC (Panel Charger/Car Charger)

2

Input Port for Charging Product with Solar Panel

DC8020

Input Port for Charging Product with Car Charger Port

DC8020

Product AC Charging Time

2.5 H

Product Charging Time with Car Charger Port

/

Product Charging Time with Solar Panel Solarsaga40

/

Product Charging Time with Solar Panel Solarsaga80

/

Product Charging Time with Solar Panel Solarsaga100

/

Product Charging Time with Solar Panel Solarsaga200

/

Product Charging Time with Solar Panel Solarsaga 500 X

/

Product Charging Time with Roof High Voltage Solar System

Not supported

Product AC Output Specification

2*AC120V,60Hz,2000WRated AC240V,60Hz,4000WRated

Maximum Instantaneous Output Power

Maximum 4000W at 120V Maximum 8000W at 240V

Number of Product AC Output Ports

2

AC Output Frequency

60HZ

Product Car Charger Port Specification

12V,10A

Number of Product Car Charger Ports

1

Number of Product USB Ports

2

Product USB-A Port Output Specification

1*USB-Aoutput:18WMax,5-6V⎓3A,6-9V⎓2A,9-12V⎓1.5A

Product Specification for Input via USB-C Port

/

Product USB-C Port Output Specification

1*USB-Coutput:100WMax,5V⎓3A,9V⎓3A,12V⎓3A,15V⎓3A,20V⎓5A

Temperature Range for Product Charging

-20-45℃

Discharge Temperature Range

-20-45℃

Storage Temperature Range

1year:0~25°C,3months:0~45°C,1month:-20~45°C

Material of Product Housing

PC + ABS High-Strength Plastic

Accessories

1*Portable power station 1*Warranty Card 1*AC Charging Cable 1*Product User Manual 1*Solar Panel Connection Guide

Noise Level of Product Cooling Fan

≤ 30dB

Standby Power Consumption

≤25 W

Does it Have UPS Function

10ms

Are additional accessories required to connect the solar panel?

■ Regarding the necessity of purchasing additional series boxes: 1 or 2 Panels: Can be connected using the included cable. No purchase required. 4 Panels: Requires 2 × SolarSaga Adapters (for Pro/Plus/V Series).

Does the AC charging cable include a grounding wire, and how should it be used?

Grounding wire included.

Maximum Number of Solar Panels That Can Be Connected

Supports connection for 1 panel / 2 panels / 4 panels.

Supports Charging with Jackery Products?

Support

Maximum AC output power during simultaneous charging and discharging

1440W

Can the product connect to 2 solar panels

Supported. However, since the two DC input ports are connected in parallel, they do not support simultaneous connection of solar panels with different wattages. In other words, a configuration such as 100W on one port and 200W on the other port is not supported.

Can the product connect to 3 or more solar panels

Three panels are not supported. Connecting four panels is supported, but the solar panel models must be identical.

Are the two DC input ports parallel or independent

Parallel

Connection rules when both DC ports are used simultaneously

This device has two DC input ports, and each port can connect up to 2 solar panels. The number and model of panels connected to each port must be identical.

Can the product be charged by a solar panel and a car charger at the same time?

Not supported.

Can the product be charged using two car charging cables at the same time?

Not supported.

Does the product support battery packs?

Not supported.

Does the product support app control?

Supported.

Does it have waterproof and dustproof?

Not supported.

Can the AC output frequency be switched

Not supported.

Does the product support parallel operation

Supported.

Is the AC charging cable UL certified?

Yes, the AC charging cable included with the portable power supply bears the UL certification mark, ensuring safe use.

Does it have LED lighting

Not supported.

Can it be charged using a car fast charger?

Supported.

Charging time with car fast charger

/

Can wall charging and Solar charging be performed simultaneously

Supported.

Can the Energy Saving Mode be turned off

Supported.

Can the device status be monitored via the app

Supported.

Can the AC/DC output be turned on/off via the app

Supported.

Can the LED display be turned on or off and scheduled via the app

Supported.

Can the LED light be turned on or off via the app?

Supported.

Does the app allow setting auto-shutdown?

Supported.

Is it possible to set Battery Saving Mode in the app

Supported.

Is it possible to set Quiet Charging Mode in the app

Supported.

Can product specifications be viewed in the app

Supported.

Can the user manual be accessed through the app

Supported.

Can the device be shared using a QR code

Supported.

Can the temperature display be set in the app

Supported.

Is it possible to configure the system language through the app

Supported.

Is it possible to set the Battery saving mode (15% to 85%) in the app

Supported.

Can the charging range for Battery saving mode be adjusted via the app

Supported.

Is it possible to set the emergency charging mode in the app

Supported.

Does it have solar power generation analytics?

Supported.

Does it have a timed charging (charging plan) function

Supported.

Does this system have a Self-powered Mode

Supported.

Can the Wi-Fi MAC address be viewed in the app

Supported.

Is it possible to set AC charging speed in the app

Supported.

Can the AC/DC output time be set through the APP?

Supported.

Plug type and usage scenario for the 30A output port on Power Station

/

Plug type and usage scenario for the 50A output port on Power Station

Plug/Socket Type: NEMA 14-50 (Output: 120V/240V AC) Main Applications: A. Home Backup Power Systems Examples: Connecting to a transfer switch or generator inlet box to provide backup power for refrigerators, freezers, lighting, internet equipment, well pumps, and other essential household circuits during outages. B. RV and Camper Power Supply Examples: Powering 50A RVs, travel trailers, and motorhomes, including air conditioners, microwaves, refrigerators, water heaters, and other onboard appliances. C. High-Power Tools and Equipment Examples: Air compressors, pressure washers, workshop equipment, construction tools, and other devices requiring a 120V/240V power source. D. Off-Grid and Emergency Power Applications Examples: Temporary power for cabins, outdoor events, emergency response operations, mobile command stations, and remote work sites. Important Note: The 50A NEMA 14-50 port provides a standard 120V/240V connection interface. actual output power is limited by the maximum output power of the energy storage system. The 50A socket only represents the current it can withstand.

Does it support pass-through charging?

Supported.

How to reset the device

Press the POWER+DC/USB button for 3 seconds

Can Wi-Fi/Bluetooth be reset separately

Supported.

How to reset Wi-Fi/Bluetooth

Press the POWER+DC/USB button for 3 seconds

How to activate the Bluetooth/Wi-Fi module after it has been turned off.

DC+AC button 1S

How much battery capacity is typically lost due to self-discharge when the power station is not in use?

Around 1%-3% per month

About app settings when the battery is fully depleted For example, if the current app settings are “Battery Saving Mode

Disabled” and “Auto Power-Off: Never,” will these settings remain the same after the battery is drained and then recharged? Or will they be reset to default?: These settings will remain unchanged once the battery is restored, provided no reset is performed.

Is the neutral wire floating or Bonded?

floating
