Can third-party solar panels be used with Jackery Power Stations?

1. Check the Connection Terminals

■ Explorer 100 Plus / Portable Power Station 300 Plus / 240NEW

To use solar panels with these models, a DC8020 - USB-C Trans Jack is required.

If the solar panel’s connector is not DC8020 standard, it cannot be connected.

Connection example:

Solar Panel ⇒ DC8020 - USB-C Trans Jack ⇒ 100 Plus / 300 Plus / 240NEW USB-C In/Out Port

■ Portable Power Stations 240 / 300 / 500 / 880 / 1000

DC input port size: DC7909 (Outer diameter 7.9 mm, inner diameter 5.5 mm, inner pin 0.9 mm)

Note: Inner wall is positive, outer wall is negative.

■ Portable Power Stations 1500, v2 series, Plus series, 1500 Ultra

DC input port size: DC8020 (Outer diameter 8.0 mm, inner diameter 5.5 mm, inner pin 2.0 mm)

Note: Inner wall is positive, outer wall is negative.

2. Check the Open-Circuit Voltage and Maximum Power Current (Imp)  of the Solar Panel

Please ensure that the solar panel’s open-circuit voltage (Voc) and current (Imp) are within the DC input voltage and current range of the portable power station.

Connecting a solar panel with a voltage exceeding the input limit may prevent charging or cause product damage.

3. Important Notes

Solar panels that match the above terminal size and open-circuit voltage can be connected.

However, compatibility and operational guarantee with third-party products are not provided.

When using third-party products, please exercise caution and ensure safe usage.
