SolarSaga 200W (JS-200E) Basic Information

Updated
Share
SolarSaga 200W (JS-200E) Basic Information - Jackery

Model JS-200E Foldable 4-fold Folded Size 600x597x40 mm Unfolded Size 2279x597x25 mm Connector Port Specifications DC8020 Cable Length 3m Weight 6.5...

Table of Contents
VIEW MORE

Model

JS-200E

Foldable

4-fold

Folded Size

600x597x40 mm

Unfolded Size

2279x597x25 mm

Connector Port Specifications

DC8020

Cable Length

3m

Weight

6.5 Kg±0.3 kg

Maximum Power Output (Ideal)

200W

Conversion Efficiency

25％

Rated Voltage

18V±5%

Rated Current

12.6A±5%

Open Voltage

22V±5%

USB-A Port Output Specifications

5V/2.4A

USB-C Port Output Specifications

5V/3A

Operating Temperature Range

-20~65℃

Minimum Power Output on Sunny Summer Days

120w以上

Accessory

Multi-function charging cable ×1 DC8020 to DC7909 adapter ×1 User manual ×1

Product Availability

Yes

Warranty

Standard: 3 years; Extended: up to 5 years with registration

Adapter

DC8020 to DC7909

Waterproof Rating

IP68

Main Use Case

Outdoor (balcony, backyard, campsite, etc.)

Does it have support feet?

On the back

Disclaimer:

The runtime mentioned for appliances powered by Jackery is for reference only. Actual runtime may vary under different conditions. Please refer to real-world performance for accurate results.
