Jackery Grounding Adapter

1. Safe Grounding for Sensitive Devices
The Jackery Grounding Adapter is designed to provide a safe, grounded power connection when using your Jackery power station to operate sensitive electronics, home appliances, or electric vehicle charging equipment. This adapter ensures proper grounding compliance for enhanced safety during use. *(Source: Page 8, "PRODUCT INTRODUCTION")*

2. Simple Plug-and-Play Setup
To set up, first confirm the power station is not connected to any grid AC socket. Then connect the USB‑A cable of the adapter to the corresponding USB‑A output port on your power station, and connect the AC charging cable from the adapter's AC port to the power station's 120V AC output port. Turn on the station and activate both the DC and AC power buttons. Once connected, the LCD screen and app will display a grounding icon.

3. Supports Electric Vehicle (EV) Charging
To charge an EV using the adapter, complete the basic setup first, then connect your EV charging cable from the vehicle's charging port to another available 120V AC or 240V AC output port on the power station, and start charging according to your EV charger's instructions. Always refer to both manuals for specific compatibility and safety instructions.

4. Compatible with Multiple Jackery Models
For supported products, please refer to the adapter's FAQ or visit the relevant power station pages at www.jackery.com. Port connection varies by model: with HP3600 Pro Max, connect to the station's USB‑A output port; with E5000 Plus/HP5000 Plus, connect to the right USB‑A port; with HP3600 Plus, connect to the left USB‑A port.

5. Important Safety and Warranty Information
Do not use grid power to charge the station while the adapter is connected. When using with E5000 Plus/HP5000 Plus or HP3600 Pro Max, the parallel port cannot be used while the adapter is connected. The product comes with a 12‑month standard warranty for the original consumer purchaser, covering defects in workmanship and material under normal use.
